Features:

1. Support JST plug battery.

2. Support multiple balance charge such as imax B6, B6AC and so on.

3. Mini Size: 93 * 53 * 28mm, easy to carry and durable use.

4. Support multiple Batteries: could charge 2S or 3S LiPo, LiFe and Li-ion battery.

5. Reduce charging time: the parallel charging board could help to charge up to 8 batteries at the same time instead of balancing batteries 1 by 1

Specification:

Item Name: Battery parallel charging board

Support Battery Cell: 2S/3S

Support Battery: LiPo, LiFe, Li-ion

Support Charger: imax B6 B6AC balance charger etc.

Support Battery Connector: JST

Current Input Connector: XT60, 4mm banana plug

Total Current: <10A

Jst Output Current for 1: <3A

Total Current of Balancing Port: <3A

Total Voltage: <36V

Dimension: 93 * 53 * 28mm

Weight: 76g

Please Note:

the parallel charging board only support charging 1-8pcs batteries with the same voltage (2s or 3s) and the same type (LiPo, LiFe or Li-ion) at the same time.

Package Information:

Package size: 12 * 11 * 4cm / 4.7 * 4.3 * 1.6in

Package weight: 96g / 3.4oz

Poly bag Package

Any problem, please contact with us at once.

Package Included:

1 x JST Parallel Charging Board
